| Characteristics | Items | Types | |||||||
| S-1000/ VF85 |
VS-3000/ VJ95 |
VS-4000/ SC95 |
S-3000/ VF95 |
S-4000/ DF95 |
S-5000/ GF95 |
S-6000/ GF98 |
|||
| Physical Properties | Bulk Density (g/cm3) | 2.3-2.5 | 2.5-2.7 | 2.4-2.6 | 2.5-2.7 | 2.5-2.7 | 2.6-2.9 | 2.7-3.0 | |
| Apparent Porosity (%) | 20-25 | 17-22 | 18-21 | 17-22 | 15-20 | 14-18 | 14-18 | ||
| Water Absorption (%) | 6-8 | 6-8 | 6-8 | 6-8 | 6-7.5 | 4-6 | 4-6 | ||
| Bending Strength (Mpa) | Indoor Temp. | 40-50 | 45-55 | 55-65 | 45-55 | 50-60 | 55-65 | 60-70 | |
| High. Temp. | >40 | >30 | >40 | >30 | >40 | >50 | >60 | ||
| 1200°C | 1350°C | 1200°C | 1350°C | 1350°C | 1350°C | 1350°C | |||
| Thermal Expansion Coefficient (x10-6/°C)(25-1000°C) |
5.4-5.9 | 5.6-6.0 | 5.0-5.5 | 5.6-6.0 | 5.7-6.1 | 5.8-6.2 | 5.8-6.2 | ||
| Thermal Shock Resistance | Good | Very Good | Very Good | Very Good | Very Good | Very Good | Very Good | ||
| Max. Working Temp. (°C) | 1000 | 1200 | 1200 | 1200 | 1300 | 1350 | 1400 | ||
| Composition | A12O3 (%) | 67-69 | 70-72 | 35-45 | 70-72 | 70-72 | 70-72 | 72-74 | |
| SiO2 (%) | 25-27 | 23-25 | 15-20 | 23-25 | 21-23 | 21-23 | 17-19 | ||
| ZrO2 (%) | – | 3-5 | – | 3-5 | 4-7 | 4-7 | 5-8 | ||
| Fe2O3 (%) | 0.4-0.6 | 0.4-0.6 | 0.3-0.4 | 0.4-0.6 | 0.3-0.4 | 0.3-0.4 | 0.2-0.3 | ||
| SiC | – | – | 45-55 | – | – | – | – | ||
| Application | Roller Kiln | √ | √ | √ | √ | √ | |||
| Glazed Wall Tile | √ | √ | √ | √ | √ | ||||
| Glazed Floor Tile | √ | √ | √ | √ | √ | ||||
| Porcelain Tile | √ | √ | √ | √ | √ | √ | √ | ||
| Tableware | √ | √ | √ | √ | |||||
| Magnetic Ceramics | √ | √ | √ | ||||||
| Microcrystal Tile | √ | √ | √ | ||||||
| Sanitary Ceramics | √ | √ | √ | ||||||
| Hi-tech Ceramics | √ | √ | |||||||
| Specification | O.D. Φ21-70mm, Length up to ≤4800mm | ||||||||
| Linearity | ≤0.07% x L | ||||||||
